| Tempat asal: | Jiangsu, Tiongkok (Daratan) |
| Nama merek: | Jkongmotor |
| Sertifikasi: | CE, ROHS,ISO9001 |
| Nomor model: | nema 23 nema34 |
| Kuantitas min Order: | 3-10 buah |
|---|---|
| Harga: | US $29.5 -93 / Pieces |
| Kemasan rincian: | <i>with export carton .</i> <b>dengan karton ekspor.</b> <i>big quantity with pallet</i> <b>jumlah b |
| Waktu pengiriman: | Untuk sampel, 7-15 hari/Untuk batch, 15-25days |
| Syarat-syarat pembayaran: | T/T, PayPal, Western Union, L/C |
| Menyediakan kemampuan: | 30000 PCS/BULAN |
| Fase: | 2 | Jenis: | Hibrida |
|---|---|---|---|
| Langkah Sudut (derajat): | 1.8 | Menahan Torsi: | 3,4kg.cm - 12,2N.m |
| Arus / Fase: | 0,2A - 6A | Nama Produk: | Motor stepper NEMA34 dengan gigi cacing |
| Cahaya Tinggi: | 3 Axis Cnc Kit Stepper Driver,12NM Cnc Kit Stepper Driver,Hybrid Nema34 Stepper Motor |
||
Nema 34 12N.M 3 Axis Cnc Kit Stepper Driver Dan Stepper Motor
Rasio Gearbox: 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100
Spesifikasi Motor Stepper Nema23:
| Model nomor. | Sudut Langkah | Panjang Motor |
Saat ini /Fase |
Perlawanan /Fase |
Induktansi /Fase |
Menahan Torsi | # Prospek | Torsi Penahan | Inersia Rotor | Massa |
| (°) | (L)mm | A | Ω | mH | Nm | TIDAK. | g.cm | g.cm | Kg | |
| JK57HS41-2804 | 1.8 | 41 | 2.8 | 0,7 | 1.4 | 0,55 | 4 | 250 | 150 | 0,47 |
| JK57HS51-2804 | 1.8 | 51 | 2.8 | 0,83 | 2.2 | 1.01 | 4 | 300 | 230 | 0,59 |
| JK57HS56-2804 | 1.8 | 56 | 2.8 | 0,9 | 2.5 | 1.2 | 4 | 350 | 280 | 0,68 |
| JK57HS64-2804 | 1.8 | 64 | 2.8 | 0,8 | 2.3 | 1 | 4 | 400 | 300 | 0,75 |
| JK57HS76-2804 | 1.8 | 76 | 2.8 | 1.1 | 3.6 | 1.89 | 4 | 600 | 440 | 1.1 |
| JK57HS82-3004 | 1.8 | 82 | 3 | 1.2 | 4 | 2.1 | 4 | 1000 | 600 | 1.2 |
| JK57HS112-3004 | 1.8 | 112 | 3 | 1.6 | 7.5 | 3 | 4 | 1200 | 800 | 1.4 |
Spesifikasi Motor Stepper Nema34:
|
Model nomor. |
Sudut Langkah |
Panjang Motor |
Saat ini /Fase |
Perlawanan /Fase |
Induktansi /Fase |
Menahan Torsi |
# Prospek |
Torsi Penahan |
Inersia Rotor |
Massa |
| (°) | (L)mm | A | Ω | mH | Nm | TIDAK. | Kg.cm | g.cm | Kg | |
| JK86HS68-3004 | 1.8 | 68 | 3.0 | 1.2 | 7.1 | 3.5 | 4 | 0,8 | 1000 | 1.7 |
| JK86HS68-2808 | 1.8 | 68 | 2.8 | 1.4 | 3.9 | 2.4 | 8 | 0,8 | 1000 | 1.7 |
| JK86HS78-5504 | 1.8 | 78 | 5.5 | 0,46 | 4 | 4.6 | 4 | 1.2 | 1400 | 2.3 |
| JK86HS78-4208 | 1.8 | 78 | 4.2 | 0,75 | 3.4 | 4.6 | 8 | 1.2 | 1400 | 2.3 |
| JK86HS115-6004 | 1.8 | 115 | 6.0 | 0,6 | 6.5 | 8.7 | 4 | 2.4 | 2700 | 3.8 |
| JK86HS115-4208 | 1.8 | 115 | 4.2 | 0,9 | 6 | 8.7 | 8 | 2.4 | 2700 | 3.8 |
| JK86HS155-6204 | 1.8 | 155 | 6.2 | 0,75 | 9 | 12.2 | 4 | 3.6 | 4000 | 5.4 |
| JK86HS155-4208 | 1.8 | 155 | 4.2 | 1.25 | 8 | 12.2 | 8 | 3.6 | 4000 | 5.4 |
